Overview
The Yokogawa ADV869-P00 is an I/O interface module used in CENTUM and ProSafe control systems. It provides reliable signal processing, stable communication with the controller, and integrated diagnostics for industrial automation applications.
General Information
Part Number: ADV869-P00
Manufacturer: Yokogawa
Series: ADV800 Series
Type: I/O Interface Module
Mounting: Installed in system I/O base or rack
Technology: Signal conditioning, electrical isolation, internal diagnostics
Power Specifications
Supply Voltage: Backplane supplied (5 V / 24 V depending on system)
Power Consumption: < 6 W
Input Source: System backplane
Protection: Overcurrent and isolation protection
Indicators: LEDs for module status and channel activity
Communication & Interface
System Bus: Yokogawa ESB/ICB bus
I/O Functions: Industrial analog/digital signal interface
Diagnostics: On-board module self-check and line monitoring
Operator Interface: LED indicators, configuration selectors
Reset Features: Software reset or power-cycle reset
I/O & Channels
Channels: Model-specific mixed or dedicated I/O channels
Signal Support: Supports standard industrial signal formats
Isolation: Channel and system-level isolation protection
External Load: Not applicable (module is signal interface only)
Environmental
Operating Temperature: 0 to +55 °C
Humidity: Up to 90% RH (non-condensing)
Protection Rating: IP20 (for cabinet installation)
Dimensions & Weight
Dimensions (L × W × H): 130 × 127.2 × 32.8 mm
Weight: ~ 0.3 kg
