Overview
The OVATION 1C31110G01 is an analog input module designed for Emerson’s OVATION Distributed Control System (DCS). It collects analog signals from field transmitters and converts them into digital data for use by the controller. The module provides stable, high-accuracy measurement performance with integrated diagnostics for reliable operation in industrial automation environments.
General Information
Part Number: 1C31110G01
Manufacturer: Emerson
Series: OVATION I/O Modules
Type: Analog Input Module / Interface Module
Mounting: Rack installation inside OVATION I/O chassis
Technology: Analog signal conversion, isolation, diagnostic monitoring
Power Specifications
Supply Voltage: 5 V DC or 24 V DC supplied via the backplane
Power Consumption: ≤ 6 W
Input: Powered through backplane connection
Protection: Overvoltage and reverse-polarity protection
Indicators: LEDs for power, module status, and fault detection
Communication & Interface
Field Signal Input: Supports standard analog signals such as 4–20 mA or 1–5 V (depending on configuration)
Controller Interface: Converts analog sensor signals into digital data for OVATION DCS
Diagnostics: Signal integrity checks, channel health monitoring, fault reporting
Operator Interface: LED indicators for operating status and alarms
Reset Features: Soft reset supported through OVATION engineering tools
I/O & Channels
Analog Input Channels: Up to 8 channels per module
Relay / Output Channels: None
External Load Support: Not applicable
Environmental
Operating Temperature: 0 to 55 °C
Humidity: 10–90% RH, non-condensing
Protection Rating: IP20, suitable for installation in a protected control cabinet
Dimensions & Weight
Dimensions (L × W × H): 160 × 40 × 120 mm
Weight: ~0.45 kg
