Yokogawa AVR10D-A22040 Duplex V-Net Router

Overview

The Yokogawa AVR10D-A22040 is a duplex V-Net router designed for reliable industrial communication in distributed control systems. It provides redundant network routing with automatic failover, ensuring continuous data exchange and high availability in mission-critical process environments.

General Information

Part Number: AVR10D-A22040
Manufacturer: Yokogawa
System Series: V-Network / Industrial Communication Series
Brand: Yokogawa (Japan)
Country of Origin: Japan
Type: Duplex V-Net Router
Function: Redundant network routing and communication management
Installation: Rack-mounted module for control system cabinets
Compatibility: Yokogawa V-Net and distributed control systems
Technology: Dual-redundant architecture with automatic failover switching

Power Specifications

Supply Voltage: 24 V DC (industrial standard)
Power Consumption: Typically ≤ 25 W
Input Power Source: System rack or control cabinet power supply
Protection: Over-voltage, surge, and reverse polarity protection
Status Indication: LED indicators for power, link, and redundancy status

Communication & Interface

Network Type: V-Net industrial communication system
Architecture: Duplex redundant routing system
Ports: Multiple system-dependent industrial network interfaces
Data Transfer: High-speed deterministic communication routing
Diagnostics: Link monitoring, network health checks, fault detection, redundancy status indication
System Integration: Fully compatible with Yokogawa distributed control architecture

Environmental

Operating Temperature: 0 to +60 °C
Storage Temperature: −20 to +70 °C
Humidity: 5%–95% RH, non-condensing
Vibration Resistance: Industrial control cabinet standard
Protection Class: IP20 (rack-mounted installation)

Dimensions & Weight

Dimensions (L × W × H): 482.6 × 132.5 × 169 mm
Weight: 5.8 kg

High-availability networking for continuous industrial control performance!
