Overview
The Yokogawa ADV151-P10-S2 is an analog input module designed for stable and accurate signal acquisition in Yokogawa DCS environments. It provides reliable processing of field analog signals and ensures consistent performance in industrial process automation systems.
General Information
Part Number: ADV151-P10-S2
Brand / Country of Origin: Yokogawa / Japan
Manufacturer: Yokogawa Electric Corporation
Series: ADV Series
Type: Analog Input Module
Mounting: Baseplate or rack-mounted installation within the I/O subsystem
Function: Converts and conditions field analog signals for controller processing
Power Specifications
Supply Voltage: Provided through the I/O baseplate backplane
Power Consumption: Low-power, optimized for continuous operation
Input Power Source: Internal DCS power supply distribution
Protection: Built-in isolation and signal protection circuits
Indicators: Front-panel LEDs for module status and channel operation
Communication & Interface
Interface Type: Connection to the Yokogawa I/O bus
Signal Type: Multi-channel analog signal acquisition
Data Handling: Stable sampling, conversion, and noise-filtered transmission
Diagnostics: Module self-check, signal loop monitoring, status indication
Operator Interaction: LED indicators for online, error, and functional states
Environmental
Operating Temperature: Standard industrial range suitable for control cabinets
Humidity: Up to 95% RH, non-condensing
Installation Environment: Clean control cabinet with adequate airflow
Protection Rating: Suitable for enclosed industrial environments
Dimensions & Weight
Dimensions (L × W × H): 107.5 × 130 × 32.8 mm
Weight: ~0.3 kg
