Woodward 8200-188 | Actuator Driver Module Quality Assurance

Overview

The Woodward 8200-188 is an actuator driver module designed for industrial engine and turbine control systems. It provides stable and precise actuation signals, ensuring accurate positioning and response in demanding environments. The module is widely used in gas turbines, steam turbines, and large engine control applications where reliable motion control is critical.

General Information

Brand: Woodward
Country of Origin: USA
Product Type: Actuator Driver Module
Application: Turbine control, compressor systems, large engine automation
Series: Woodward 8200 Series
Function: Converts control commands into stable actuator drive output
Mounting: Rack or panel-mounted control chassis

Power Specifications

Input Voltage: 24 VDC (typical)
Power Draw: Low to moderate, optimized for continuous operation
Drive Output: Regulated actuator drive signals
Internal Protection: Overcurrent protection, load fault detection, thermal safeguards
Signal Integrity: Filtered output for stable and noise-free actuator control

Communication & Interface

System Interface: Connects directly to Woodward control systems
Control Signals: Accepts system logic commands for actuator positioning
Feedback Handling: Supports closed-loop operation with feedback input
Indicators: Onboard LEDs for module health, output status, and fault conditions
Connectivity: Standard industrial terminal connections for input/output wiring

Environmental

Operating Temperature: −20°C to +70°C
Storage Temperature: −40°C to +85°C
Humidity: Up to 95% RH, non-condensing
Construction: Rugged industrial PCB with protective coating
Compliance: Suitable for harsh turbine and engine control environments

Dimensions & Weight

Dimensions: 160  × 100  × 40 mm
Weight: Approx. 0.45 kg

Brand-new and original items in full stock, 24-hour customer service available.
