Overview
The OVATION 1X00024H01 is an analog output module used in Emerson’s Ovation distributed control system. It converts digital control signals from the central controller into precise analog outputs for actuators, valves, and other field devices.
General Information
Part Number: 1X00024H01
Manufacturer: Emerson
Country of Origin: USA
Module Type: Analog Output Module
Application: Provides accurate analog output signals to field devices for process control applications
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: Approximately 10 W
Protection: Overload and short-circuit protection to ensure safe operation of connected devices
Communication & Interface
Interface: Connected via Ovation system backplane
I/O Capacity: Supports multiple analog output channels depending on configuration
Diagnostics: Monitors output signal status and detects faults
I/O & Channels
Analog Outputs: Multiple channels for driving actuators, valves, or other analog-controlled devices
Digital Inputs/Outputs: None
External Load Support: Drives standard process control loads
Environmental
Operating Temperature: −40 to +70 °C
Humidity: Up to 95% RH, non-condensing
Mounting: Rack or cabinet installation in Ovation control systems
Dimensions & Weight
Dimensions (L × W × H): 140 × 60 × 25 mm
Weight: ~0.3 kg
