Overview
The Honeywell CC-PDIH01 51405041-175 is a high-level digital input module used in Honeywell Series-C and Experion control systems. It receives 24 V DC discrete input signals and provides reliable monitoring with advanced diagnostics.
General Information
Part Number: CC-PDIH01 51405041-175
Manufacturer: Honeywell International Inc.
Brand / Country of Origin: Honeywell / USA
Type: Digital Input Module
Mounting: Installed on Series-C I/O rack
Technology: 24 V DC input with built-in diagnostics and fault detection
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: Approx. 5 W
Input Type: Discrete signal inputs
Protection: Overvoltage and short-circuit protection
Indicators: LEDs for channel status and fault indication
Communication & Interface
Interface: Series-C I/O backplane communication
Diagnostics: Supports open-wire and signal integrity detection
Redundancy: Compatible with redundant I/O configuration
Response Time: Fast input detection for real-time control systems
Environmental
Operating Temperature: −20 °C to +70 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Designed for industrial control cabinet installation
Dimensions & Weight
Dimensions (L × W × H): Approx. 300 × 200 × 65 mm
Weight: Approx. 0.36 kg
