Overview
The Honeywell CC-PAON01 51410070-176 is a high-performance analog output module for industrial automation and process control. Manufactured by Honeywell International Inc., USA, it converts digital signals into precise analog outputs for actuators, indicators, and recording devices.
General Information
Manufacturer: Honeywell International Inc.
Country of Origin: USA
Part Number: CC-PAON01 51410070-176
Product Name: Experion® PKS Series C Analog Output Module
Product Type: High-Level Analog Output Module
Channels: 16
Output Types Supported: 4–20 mA, 0–20 mA
Mounting: Rack-mounted module
Application: Industrial automation, process control, DCS integration
Power Specifications
Supply Voltage: 24 V DC (±10%)
Power Consumption: Approx. 4 W
Field Power: Provided by external sources
Isolation: 500 V AC channel-to-channel, 1500 V AC channel-to-system
Communication & Interface
Signal Type: 4–20 mA and 0–20 mA analog output
Interface: HART 7 protocol support
Data Update Rate: Standard process scan rates
Diagnostics: Open circuit, short circuit, overrange/underrange detection
Redundancy: Supports redundant configurations
Environmental
Operating Temperature: 0°C to 60°C
Storage Temperature: −40°C to +85°C
Relative Humidity: 5% to 95% RH, non-condensing
Vibration Resistance: Compliant with industry standards
Protection Class: IP20 (installed in control cabinet)
Dimensions & Weight
Dimensions: 130 × 130 × 50 mm
Weight: Approx. 0.35 kg
