Overview
The Honeywell FC-TRO-0824 is a transformer and power module designed for use in Honeywell Experion and related control systems. It provides reliable voltage conversion and regulated power to control and I/O modules, ensuring stable operation and protection of the system.
General Information
Part Number: FC-TRO-0824
Manufacturer: Honeywell
Series: FC (Field/Control Power Modules)
Type: Transformer / Power Module
Mounting: Rack or chassis installation within control panels
Technology: Voltage conversion, power regulation, surge protection
Power Specifications
Supply Voltage: 120/240 V AC (input)
Output Voltage: 24 V DC
Power Consumption: ≤ 30 W
Input: Main AC supply from system or panel
Protection: Overvoltage, short-circuit, and reverse-polarity protection
Indicators: LED for power status
Communication & Interface
Field Interface: Provides regulated DC power to connected modules
Bus Coupler Role: Integrates power supply with control system
Diagnostics: Power fault detection and status reporting
Operator Interface: LED indicator for module status
Reset Features: Supports soft and hardware reset via system controller
I/O & Channels
Power Outputs: 24 V DC isolated outputs to connected modules
External Load Support: Supports additional field devices within rated limits
Environmental
Operating Temperature: 0 to 55 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Standard industrial cabinet environment
Dimensions & Weight
Dimensions (L × W × H): 210 × 150 × 45 mm
Weight: ~ 2.9 kg
