Overview
The Honeywell FC-SIC2030 is a smart input controller module used in Honeywell Experion and related control systems. It is designed to receive, condition, and process signals from field transmitters, providing accurate measurement and reliable integration into the control network.
General Information
Part Number: FC-SIC2030
Manufacturer: Honeywell
Series: FC (Field/Control I/O Modules)
Type: Smart Input Controller
Mounting: Rack or chassis installation within control panels
Technology: Signal conditioning, digital communication, diagnostics, and fault detection
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 10 W
Input: Powered from system backplane
Protection: Overvoltage, short-circuit, and reverse-polarity protection
Indicators: LEDs for power, communication, and fault status
Communication & Interface
Field Interface: Accepts analog signals from transmitters, including 4–20 mA
Bus Coupler Role: Integrates field signals into the main control system
Diagnostics: Signal monitoring, fault detection, and status reporting
Operator Interface: LED indicators for module status
Reset Features: Supports soft and hardware reset via system controller
I/O & Channels
Analog Inputs: Multiple channels for process measurement
Analog Outputs: Not applicable (input-focused module)
Digital Inputs/Outputs: Configurable for status monitoring
External Load Support: Can interface with external devices within rated limits
Environmental
Operating Temperature: 0 to 55 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Standard industrial cabinet environment
Dimensions & Weight
Dimensions (L × W × H): 210 × 150 × 45 mm
Weight: ~ 2.7 kg
