Overview
The Honeywell FC-PDB-0824P is a power distribution board designed for use in Honeywell Experion and related control systems. It provides reliable DC power distribution to multiple system modules, ensuring stable operation, fault protection, and monitoring across the control network.
General Information
Part Number: FC-PDB-0824P
Manufacturer: Honeywell
Series: FC (Field/Control Power Modules)
Type: Power Distribution Board
Mounting: Rack or chassis installation within control panels
Technology: Power routing, surge protection, fault detection, load monitoring
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 20 W (typical)
Input: Main DC supply from system power source
Protection: Overvoltage, short-circuit, and reverse-polarity protection
Indicators: LEDs for power status, fault, and output monitoring
Communication & Interface
Field Interface: Provides isolated DC power to control and I/O modules
Bus Coupler Role: Integrates power distribution across system modules
Diagnostics: Power fault detection, load monitoring, and status reporting
Operator Interface: LED indicators for power and fault
Reset Features: Supports soft and hardware reset via system controller
I/O & Channels
Power Outputs: Multiple isolated DC outputs to connected modules
External Load Support: Supports additional field devices within rated limits
Environmental
Operating Temperature: 0 to 55 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Standard industrial cabinet environment
Dimensions & Weight
Dimensions (L × W × H): 210 × 150 × 45 mm
Weight: ~ 2.5 kg
