Overview
The Honeywell FC-PDB-0824 is a power distribution board designed for use in Honeywell’s Experion and related control systems. It provides reliable power routing, protection, and monitoring for multiple system modules, ensuring stable operation and safety of the control network.
General Information
Part Number: FC-PDB-0824
Manufacturer: Honeywell
Series: FC (Field/Control Power Modules)
Type: Power Distribution Board
Mounting: Rack or chassis installation within control panels
Technology: Power distribution, surge protection, fault monitoring
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 20 W (typical)
Input: Main DC supply from system power source
Protection: Overvoltage, short-circuit, and reverse-polarity protection
Indicators: LEDs for power status, fault, and output monitoring
Communication & Interface
Field Interface: Provides DC power to control and I/O modules
Bus Coupler Role: Ensures power integration for modules in the system
Diagnostics: Power fault detection, load monitoring, and status reporting
Operator Interface: LED indicators for power and fault
Reset Features: Supports soft and hardware reset via system controller
I/O & Channels
Power Outputs: Multiple isolated DC outputs to connected modules
External Load Support: Supports additional field devices within rated limits
Environmental
Operating Temperature: 0 to 55 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Standard industrial cabinet environment
Dimensions & Weight
Dimensions (L × W × H): 94 x 109 x 71 mm
Weight: 0.93 kg
