Overview
The HIMA F8627 is a 4-channel analog output module designed for HIMax and HIQuad safety systems. It delivers precise 4–20 mA output signals for actuators, control valves, and other process devices, with integrated diagnostics and SIL-compliant safety performance for critical applications.
General Information
Part Number: F8627
Manufacturer: HIMA
Country of Origin: Germany
Series: F-Series I/O
Type: Analog Output Module (AO)
Mounting: Plug-in module for HIMA backplane racks
Application: Safety PLC systems, ESD, BMS, turbine and process control
Power Specifications
Supply Voltage: Powered via system backplane
Output Type: 4–20 mA analog outputs
Load Capability: Supports standard current loop loads
Protection: Short-circuit protection, overload protection, internal diagnostics
Power Consumption: Low module logic consumption
Communication & Interface
Interface Type: HIMA backplane communication
Output Channels: 4 analog outputs
Signal Type: 4–20 mA current signals
Diagnostics: Output channel health monitoring, fault detection, LED status indicators
LED Indicators: Individual LEDs for each output channel
I/O & Channels
Output Type: Analog Output (AO)
Number of Channels: 4
Isolation: Galvanic isolation between module and field wiring
Signal Accuracy: High precision for process control
Environmental
Operating Temperature: −20 to +60 °C
Humidity: Up to 95% RH, non-condensing
Installation Environment: Industrial control cabinet
Protection Rating: IP20 (installed in rack enclosure)
Dimensions & Weight
Dimensions (L × W × H): 128 × 40 × 160 mm
Weight: ~ 0.28 kg
