Overview
The GE DS200TCQAG1BGE is a control circuit board used within GE Mark V turbine management systems. It supports signal processing, command execution, and coordination of control functions, providing stable and reliable operation in gas and steam turbine environments.
General Information
Part Number: DS200TCQAG1BGE
Manufacturer: GE
Series: Mark V
Type: Control / Circuit Board
Mounting: Installs directly into the Mark V module rack
Technology: Mixed-signal processing, isolation design, onboard diagnostics
Power Specifications
Supply Voltage: Provided through the Mark V backplane
Power Consumption: Low-power board electronics
Input Source: Internal control cabinet distribution
Protection: Noise filtering and surge protection circuitry
Indicators: Status LEDs for board health and operation
Communication & Interface
Interface: Backplane connector with multiple signal channels
Function: Handles control signals, reference inputs, and system coordination
Diagnostics: Internal self-checking and fault reporting
Operator Interface: LED indicators and labeled connection points
Reset Features: Supports system-managed reset sequences
I/O & Channels
Input/Output: Mixed control and status signal channels
Relay Channels: None (logic-level board)
External Load Support: Not intended for direct power switching
Environmental
Operating Temperature: 0 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: For use inside industrial control enclosures
Dimensions & Weight
Dimensions (L × W × H): 330 × 280 × 25 mm
Weight: ~1.45 kg
