Overview
The GE DS200TCQAG1BEC is a relay output board designed for GE Mark V control systems. It provides reliable relay-based switching for various turbine and auxiliary control functions, with onboard diagnostics and robust isolation to support critical industrial operations.
General Information
Part Number: DS200TCQAG1BEC
Manufacturer: GE
Series: Mark V
Type: Relay Output Board
Mounting: Installs on Mark V control rack
Technology: Relay switching, isolation circuits, diagnostic logic
Power Specifications
Supply Voltage: Powered from Mark V backplane
Power Consumption: Low-power relay driver circuitry
Input Source: Internal system distribution
Protection: Surge suppression and noise filtering
Indicators: LEDs for relay and board status
Communication & Interface
Interface: Backplane connectors and edge connectors
Function: Executes relay output commands from the controller
Diagnostics: Built-in health monitoring and relay status feedback
Operator Interface: LED indication and labeled terminals
Reset Features: Supports system reset sequences
I/O & Channels
Relay Outputs: Multiple isolated relay channels
Load Capability: Suitable for low-to-medium power signal switching
External Load Support: Dry contact relay switching
Environmental
Operating Temperature: 0 to +60 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Industrial cabinet installation
Dimensions & Weight
Dimensions (L × W × H): 330 × 280 × 25 mm
Weight: ~0.59 kg
