GE DS200TBCAG1AAB | Terminal / Transition Board Recommended products

Overview

The DS200TBCAG1AAB is an analog I/O terminal board used in GE Mark V (DS200) turbine control systems. It provides dense field wiring termination for analog inputs and outputs, serving as a bridge between field devices and the controller.

General Information

Part Number: DS200TBCAG1AAB
Manufacturer: GE (General Electric)
Series: Mark V / DS200
Type: Analog I/O Terminal / Transition Board
Revision: AAB

Power Specifications

Supply Voltage: Not required (passive board)
Power Consumption: None
Input: Receives analog I/O wiring from field devices
Protection: Contains components to suppress signal noise and limit transient voltages

Communication & Interface

Terminal Blocks: Two screw-type terminal strips for field connection
Connectors: Two board-to-board connectors for I/O module communication
Signal Types: Supports analog inputs and analog outputs
Diagnostics: No active diagnostics on board
Operator Interface: Terminal strips and board connectors

I/O & Channels

Analog Channels: Accommodates a large number of analog I/O lines
Relay / Digital Channels: None

Environmental

Operating Temperature: Suitable for turbine control cabinet environment
Humidity: Up to 95% RH, non-condensing
Protection Rating: Industrial-grade PCB

Dimensions & Weight

Dimensions (L × W × H): 210 × 70 × 35 mm
Weight: 0.295 kg

Brand-new original products in stock, professional customer service available anytime, pricing transparent.
