GE DS200TBQDG1ACC | Extension Analog Termination Board Hot Items

Overview

The GE DS200TBQDG1ACC is an extension analog termination board used in the GE Mark V control system. It provides additional termination capacity for analog input and output signals, allowing the system to handle expanded analog wiring beyond the main termination boards.

General Information

Part Number: DS200TBQDG1ACC

Manufacturer: GE (General Electric)

Series: Mark V / DS200

Type: Extension Analog Termination Board

Mounting: Cabinet panel mounting

Technology: Passive PCB with terminal strips, connectors, and protection components

Power Specifications

Supply Voltage: Not required (passive analog board)

Power Consumption: None

Input: Receives analog signal wiring from field devices

Protection: Includes metal-oxide varistors for over-voltage protection

Indicators: None

Communication & Interface

Connectors: Multiple vertical pin connectors for system interconnection

Terminal Strips: Dual terminal strip for screw-type analog wiring

Signal Support: Termination for analog input and output channels

Diagnostics: None

Operator Interface: Terminal strip only

Reset Features: Not applicable

I/O & Channels

Analog Channels: Supports multiple analog input/output terminations

Relay Channels: None

External Load Support: None (signal-level use only)

Environmental

Operating Temperature: Suitable for turbine control cabinet environments

Humidity: Up to 95% RH, non-condensing

Protection Rating: Standard PCB coating

Dimensions & Weight

Dimensions (L × W × H): 280 × 75 × 30 mm

Weight: ~ 0.29 kg
