Overview
The GE DS200QTBAG1ADC is a termination board used in GE Mark V turbine control systems. It provides organized signal wiring for speed pickups, servo outputs, LVDT position sensors, and auxiliary analog inputs. The board acts as the interface between field instrumentation and the Mark V control modules, ensuring clean signal routing and stable connectivity.
General Information
Part Number: DS200QTBAG1ADC
Manufacturer: GE (General Electric)
Series: Mark V Series
Type: Terminal / Termination Board
Mounting: Panel or cabinet mounting with screw fasteners
Technology: Passive signal distribution for speed, servo, and LVDT channels
Power Specifications
Supply Voltage: Not required (passive board)
Power Consumption: None
Input: Accepts sensor and actuator signals routed to controller
Protection: Built-in jumpers for signal configuration and noise-reduction design
Indicators: None
Communication & Interface
Interface Type: Terminal block input/output and 40-pin ribbon connector
Signal Support: Speed pickup signals, LVDT excitation/feedback, servo outputs, analog signals
Diagnostics: Signal routing only (no active diagnostics)
Operator Interface: Terminal blocks and selectable jumpers
Reset Features: Not applicable
I/O & Channels
Relay Channels: None
External Load Support: None (signal wiring board only)
Supported Signals: Magnetic pickup, LVDT, servo valve control signals, analog feedback
Environmental
Operating Temperature: −30 to +65 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: Suitable for cabinet-mounted industrial environments
Dimensions & Weight
Dimensions (L × W × H): 212 × 150 × 35 mm
Weight: ~ 0.40 kg
