GE DS200IPCSG2ABB | IGBT P3 Snubber Buffer Board Original

Overview

The GE DS200IPCSG2ABB is a buffer (snubber) board used in GE Mark V / DS200 turbine and drive systems. Its purpose is to protect IGBT power switches by absorbing voltage spikes and smoothing switching transients within the inverter power stage.

General Information

Part Number: DS200IPCSG2ABB

Manufacturer: GE (General Electric)

Series: Mark V / DS200

Type: IGBT Snubber / Buffer Board

Mounting: Installed inside the drive or turbine control cabinet

Technology: Snubber capacitors, damping resistors, transient suppression network

Power & Electrical Characteristics

Voltage Handling: Designed to attenuate high-frequency switching transients

Circuit Role: Protects IGBT modules and stabilizes inverter switching behavior

PCB Coating: Standard coating type

Revisions: G2 series, Revision ABB

Communication & Interface

Connectors: One 4-pin connector for power path integration

Interface Role: Mounted directly in the power bridge section to absorb switching energy

Diagnostics: Passive board with no onboard indicators

Operator Interface: No LEDs, switches, or settings

I/O & Channels

I/O Channels: None (not an input/output module)

External Load Support: None; serves only as a snubber protection board

Environmental

Operating Temperature: Designed for controlled industrial cabinet conditions

Humidity: Suitable for non-condensing industrial environments

Protection Rating: Open-frame PCB (depends on enclosure for protection)

Dimensions & Weight

Dimensions (L × W × H): 160 × 160 × 120 mm

Weight: ~0.8 kg

Brand-new original products supplied, ample stock, quotes provided immediately by customer service.
