Overview
The GE IS200TBAIH1CDC is an analog input terminal board designed for high-resolution signal processing within GE Mark VI and Mark VIe control systems. It ensures reliable acquisition and conditioning of analog signals from field devices in demanding industrial applications.
General Information
Model: IS200TBAIH1CDC
Manufacturer: GE (General Electric)
Product Type: Analog Input Terminal Board
System Platform: Mark VI / Mark VIe Control System
Primary Use: Turbine and industrial automation systems
Power Specifications
Power Source: Receives power via rack backplane
Input Types: Accepts multiple analog formats (current or voltage)
Isolation: Channel-to-channel electrical isolation
Power Consumption: Low-power design optimized for I/O processing
Communication & Interface
Interface: Direct connection to I/O controller via ribbon cable
Input Channels: Supports up to 16 analog input channels
Signal Conditioning: Integrated filtering and signal scaling
Configuration: Supports system-based setup and commissioning
Environmental
Operating Temperature: 0 to 60°C
Humidity: Up to 95% RH, non-condensing
Design: Durable PCB with protective coating for industrial reliability
Installation: Typically mounted in a control cabinet or rack enclosure
Dimensions & Weight
Dimensions: 101.6 x 330.2 mm
Weight: Approx. 0.9 kg
