ABB SDCS-IOB-21 3BSE005176R0001 Input/Output Board

Overview

The ABB SDCS-IOB-21 (3BSE005176R0001) is an input/output (I/O) board designed for industrial automation and DC drive systems. It enables precise control and monitoring of connected devices, sensors, and actuators, ensuring reliable signal management for high-performance SDCS applications.

General Information

Part Number: 3BSE005176R0001

Manufacturer: ABB

Brand: ABB

Country of Origin: Switzerland / Sweden

Series: SDCS (DC Drive Control System)

Type: Input/Output Board / Interface Module

Application: Signal routing, monitoring, and control in DC drives and automation systems

Installation: Mounted inside SDCS drive cabinets or control racks

Technology: Digital and analog signal processing integrated with SDCS control logic

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 15 W

Input: Powered via SDCS system backplane

Protection: Overvoltage and reverse-polarity protection

Indicators: LEDs for power, I/O status, and fault detection

Communication & Interface

Interface Type: Digital and analog I/O channels

Bus Coupler Role: Connects SDCS controller logic to field devices

Diagnostics: Monitoring, fault detection, and status reporting

Operator Interface: LED indicators for system and channel status

Reset Features: Supports soft and hardware reset via SDCS controller

Environmental

Operating Temperature: 0 to +55 °C

Storage Temperature: −25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Cooling Method: Cabinet-based forced air cooling

Protection Class: IP20 inside industrial enclosure

Dimensions & Weight

Dimensions (L × W × H): 233.5 × 97.5 × 18.5 mm

Weight: 0.37 kg

High-performance module, ready for immediate integration into your automation system.
