ABB SDCS-IOB-21 3ADT220090R0014 Input/Output Board

Overview

The ABB SDCS-IOB-21 (3ADT220090R0014) is an input/output (I/O) board designed for industrial automation and DC drive systems. It provides reliable signal processing and interface capabilities, allowing precise monitoring and control of connected devices, sensors, and actuators within the SDCS system.

General Information

Part Number: 3ADT220090R0014

Manufacturer: ABB

Brand: ABB

Country of Origin: Switzerland / Sweden

Series: SDCS (DC Drive Control System)

Type: Input/Output Board / Interface Module

Application: Signal routing and control in DC drives and automation systems

Installation: Mounted inside SDCS drive cabinets or control racks

Technology: Digital and analog signal processing with system integration

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 15 W

Input: Powered via SDCS system backplane

Protection: Overvoltage and reverse-polarity protection

Indicators: LEDs for power, I/O status, and fault detection

Communication & Interface

Interface Type: Digital and analog I/O channels

Bus Coupler Role: Connects SDCS controller logic to field devices

Diagnostics: Provides monitoring, fault detection, and status reporting

Operator Interface: LED indicators for channel and system status

Reset Features: Supports soft and hardware reset via SDCS controller

Environmental

Operating Temperature: 0 to +55 °C

Storage Temperature: −25 to +70 °C

Humidity: Up to 95% RH, non-condensing

Cooling Method: Cabinet-based forced air cooling

Protection Class: IP20 inside industrial enclosure

Dimensions & Weight

Dimensions (L × W × H): 233.5 × 97.5 × 18.5 mm

Weight: 0.37 kg

Fast delivery available, ideal for expanding your automation system capabilities.
