ABB SDCS-BAB-F01 3ADT316400R0501 Adapter Board

Overview

The ABB SDCS-BAB-F01 is an industrial-grade adapter board designed to facilitate seamless connectivity between modules in automation systems. It provides reliable signal routing and integration, enabling smooth communication and operation across connected devices. Its compact form factor allows easy installation in space-constrained control cabinets.

General Information

Part Number: 3ADT316400R0501

Manufacturer: ABB

Brand / Country of Origin: ABB / Sweden

Series: SDCS (Signal Distribution & Control System)

Type: Adapter Board

Mounting: Panel or rack installation within industrial enclosures

Technology: High-quality PCB with industrial-grade connectors, signal conditioning, and diagnostic capabilities

Power Specifications

Supply Voltage: 24 V DC (via system backplane)

Power Consumption: ≤ 8 W

Input: Powered through connected system modules

Protection: Overvoltage, surge, and reverse-polarity protection

Indicators: LED indicators for operational status

Communication & Interface

Bus / Interface: Connects control and signal modules, enabling communication between devices

Diagnostics: Monitors connectivity, signal integrity, and reports faults

Operator Interface: LED indicators for status monitoring

Reset Features: N/A (reset handled by connected CPU or controller)

I/O & Channels: Routes multiple signals between modules depending on configuration

Environmental

Operating Temperature: −20 to +60 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 (suitable for industrial cabinet mounting)

Shock & Vibration: IEC 60068 compliant

Dimensions & Weight

Dimensions (L × W × H): 190 × 100 × 30 mm

Weight: 0.299 kg

Reliable Adapter Board, Ensuring Seamless Module Integration!
