ABB PP D113 B03-26-100100 3BHE023584R2625 AC800 Control Module

Overview

The ABB PP D113 B03-26-100100 is a high-performance AC800 control module designed for industrial automation systems. It provides precise real-time control, robust processing, and seamless integration with ABB’s AC800 automation platform. Engineered for demanding industrial environments, this module ensures reliable operation and efficient management of complex automation tasks.

General Information

Part Number: 3BHE023584R2625

Manufacturer: ABB

Brand / Country of Origin: ABB / Sweden

Series: PP / AC800

Type: AC800 Control Module

Mounting: Rack or cabinet-based installation

Technology: Industrial-grade processor, real-time deterministic execution, integrated diagnostics, and advanced control logic

Power Specifications

Supply Voltage: 24 V DC

Power Consumption: ≤ 220 W

Input: Powered via backplane connection

Protection: Surge and reverse-polarity protection

Indicators: LEDs for power, status, fault, and activity

Communication & Interface

Ethernet / Fieldbus Ports: Supports PROFIBUS, Modbus, and ABB proprietary networks

Bus Coupler Role: Interfaces control bus with field devices and connected modules

Diagnostics: Module and network supervision, fault logging, and status monitoring

Operator Interface: LED indicators and onboard configuration switches

Reset Features: Supports soft and hardware reset

I/O & Channels: Multiple integrated digital and analog I/O channels, expandable via connected modules

Environmental

Operating Temperature: 0 to +55 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 (suitable for industrial cabinet mounting)

Shock & Vibration: IEC 60068 compliant

Dimensions & Weight

Dimensions (L × W × H): 450 × 100 × 150 mm

Weight: 2.8 kg

High-Performance Control Module, Ready for Demanding Automation!
