Overview
The ABB 81EA02E GJR2366000R1000 is an auxiliary contact block designed to extend the functionality of ABB contactors and relays. It provides additional signaling contacts for control circuits, supporting monitoring, interlocking, and automation in industrial applications.
General Information
Model: 81EA02E GJR2366000R1000
Manufacturer: ABB
Product Type: Auxiliary Contact Block
Country of Origin: Sweden
Application: Enhances control and monitoring capabilities of ABB contactors and relays
Power Specifications
Supply Voltage: Compatible with standard control voltages
Current Rating: Supports auxiliary circuit currents as specified by ABB
Power Consumption: Minimal, serving primarily as a signal interface
Protection: Designed for standard industrial environmental conditions
Communication & Interface
Interface: Directly mounts on compatible ABB contactors or relays
Contacts: Normally open (NO) and normally closed (NC) auxiliary contacts
Signal Integration: Connects to control, monitoring, and interlocking circuits
Diagnostics: Status indicated through contact operation
Environmental
Operating Temperature: −25 to +60°C
Humidity: Up to 95% RH, non-condensing
Design: Industrial-grade materials for durability and long-term reliability
Mounting: Snap-on or screw mounting compatible with ABB contactors and relays
Dimensions & Weight
Dimensions: 45 × 35 × 30 mm
Weight: Approx. 0.1 kg
