Overview
The ABB 70BK06A-E HESG332194R1 is a motor protection relay designed to provide reliable protection and monitoring for low-voltage motors. It safeguards motors from overload, phase failure, and short-circuit conditions, ensuring stable operation in industrial environments.
General Information
Model: 70BK06A-E HESG332194R1
Manufacturer: ABB
Product Type: Motor Protection Relay
Country of Origin: Sweden
Application: Protection and monitoring of low-voltage motors in industrial automation systems
Power Specifications
Supply Voltage: Typically 24–48 V DC or 100–240 V AC depending on configuration
Power Consumption: Low-power design suitable for continuous operation
Protection Features: Overload, phase-loss, short-circuit, and temperature protection
Indicators: LED indicators for operational status, faults, and communication
Communication & Interface
Interface: Integrated communication ports for fieldbus or network connections
Monitoring: Real-time motor current, voltage, and thermal monitoring
Configuration: Adjustable via ABB engineering software
Diagnostics: Event logging and fault diagnostics for preventive maintenance
Environmental
Operating Temperature: −20 to +60°C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20 or installed within a control cabinet
Installation: Panel-mounted in motor control centers or switchgear
Dimensions & Weight
Dimensions: 90 × 70 × 120 mm
Weight: Approx. 0.55 kg
