Overview
The ABB 07KT98 (GJR5253100R0270) is a high-performance processor module developed for the ABB Advant Controller 400 system. It serves as the central CPU responsible for executing control logic, managing data communication, and coordinating system operations. Known for its stability and durability, the module is widely applied in process automation, manufacturing, and industrial control environments.
General Information
Brand: ABB
Country of Origin: Sweden
Part Number: GJR5253100R0270
Series: Advant Controller 400
Product Type: Processor Module / CPU Unit
Mounting Method: Rack-mounted in the Advant system chassis
Function: Executes control logic, communication management, and process coordination
Technology: High-speed microprocessor with integrated diagnostics and communication interface
Power Specifications
Supply Voltage: 24 V DC
Power Consumption: ≤ 10 W
Input Source: Supplied via the system backplane
Protection Features: Overvoltage, reverse polarity, and surge protection
Indicators: LED lights for power, operation, and fault conditions
Communication & Interface
Communication Ports: System bus, serial interface, and I/O bus connections
Supported Protocols: Advant fieldbus and internal system communication standards
Diagnostics: Built-in self-test and fault indication via status LEDs
Configuration: Performed through engineering or maintenance software tools
Reset Options: Supports software and hardware reset functions
Environmental
Operating Temperature: 0 to +55 °C
Storage Temperature: −40 to +70 °C
Humidity: Up to 95% RH, non-condensing
Protection Rating: IP20 (for cabinet installation)
Cooling Method: Natural convection cooling
Dimensions & Weight
Dimensions (L × W × H): 240 × 140 × 85 mm
Weight: Approx. 1.6 kg
