Allen Bradley 22F-D018N104 PowerFlex 4M AC Drive

Overview

The Allen Bradley 22F-D018N104 PowerFlex 4M AC Drive is a compact variable frequency drive designed for dependable motor speed control in industrial automation applications. It provides efficient operation, flexible configuration, and integrated protection features for conveyors, pumps, fans, and general-purpose machinery.

The drive supports easy commissioning, adjustable parameters, and diagnostic monitoring to enhance system reliability and maintain stable motor performance.

General Information

Part Number: 22F-D018N104

Brand: Allen Bradley

Country of Origin: USA

Series: PowerFlex 4M

Type: AC Variable Frequency Drive

Application: General-purpose motor control

Mounting: Panel mounting

Control Method: Sensorless vector control and V/Hz control

Motor Compatibility: Three-phase AC induction motors

Protection Features: Overcurrent, overload, overvoltage, undervoltage, and short-circuit protection

Power Specifications

Input Voltage: 480 V AC

Input Phase: Three-phase

Output Power: 7.5 kW

Output Current: Approx. 18 A

Output Frequency: 0 to 400 Hz

Control Voltage: 24 V DC digital inputs

Motor Protection: Electronic overload protection

Drive Technology: PWM inverter technology for efficient motor operation and smooth speed regulation

Communication & Interface

Communication Interface: RS-485 serial communication port

Communication Protocol: Modbus RTU

Programming Interface: Integrated keypad and parameter configuration

Digital Inputs: Programmable inputs for start, stop, and control functions

Analog Inputs: Configurable analog reference input

Outputs: Programmable relay output signals

Diagnostics: Fault monitoring, alarm indication, and operating status feedback

Environmental

Operating Temperature: −10 to +50 °C

Storage Temperature: −40 to +85 °C

Humidity: 0 to 95% RH, non-condensing

Installation Environment: Industrial control cabinet applications

Altitude: Up to 1000 m without derating

Cooling Method: Air cooling

Dimensions & Weight

Dimensions (L × W × H): 260 × 130 × 180 mm

Weight: 4.8 kg

Limited Stock Available – Get the Parts You Need Today!
