Allen Bradley 2198-ABQE Kinetix 5700 EtherNet/IP Encoder Output Module

Overview

The Allen Bradley 2198-ABQE Kinetix 5700 EtherNet/IP Encoder Output Module is a high-performance motion control accessory designed to provide encoder output functions within Kinetix 5700 servo drive systems. It enables reliable position feedback transmission and supports coordinated motion applications through EtherNet/IP-based control architectures.

General Information

Part Number: 2198-ABQE

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: Kinetix 5700

Type: EtherNet/IP Encoder Output Module

Function: Encoder signal output and motion feedback interface

System Compatibility: Kinetix 5700 Servo Drive Systems

Mounting Type: DIN rail mounting

Module Design: Compact modular motion control component

Status Indicators: LED indicators for module operation and communication status

Power Specifications

Supply Voltage: 24 V DC

Power Source: Control power supply input

Power Consumption: Low power operation

Power Input Type: DC control power

Protection Functions: Overvoltage, short circuit, and thermal protection

Communication & Interface

Communication Interface: EtherNet/IP

Network Function: High-speed communication with Logix controllers and motion systems

Encoder Output: Supports encoder signal distribution and feedback transmission

Connection Type: EtherNet/IP network interface

Configuration Method: Controller-based configuration through automation software

Diagnostics: Module status monitoring, communication diagnostics, and fault reporting

Environmental

Operating Temperature: 0 to 50 °C

Storage Temperature: -40 to 85 °C

Humidity: Up to 95% RH, non-condensing

Installation Environment: Industrial control cabinet environment

Protection Rating: IP20

Dimensions & Weight

Dimensions (H × W × D): 155 × 50 × 120 mm

Weight: 0.5 kg

New Arrival – Ready for Advanced Motion Control Applications
