Allen Bradley 20-HIM-B1 PowerFlex Human Interface Module

Overview

The Allen Bradley 20-HIM-B1 PowerFlex Human Interface Module is a compact operator interface designed for PowerFlex AC drives. It provides convenient access to drive parameters, monitoring functions, and configuration settings through a user-friendly keypad and display interface, helping simplify drive setup and maintenance operations.

General Information

Part Number: 20-HIM-B1

Manufacturer: Allen Bradley

Brand: Allen Bradley

Country of Origin: United States

Series: PowerFlex HIM

Type: Human Interface Module

Display Type: LCD Display

Function: Drive configuration, parameter adjustment, and status monitoring

Compatibility: PowerFlex AC Drive Series

Mounting Type: Drive-mounted installation

Interface Style: Operator keypad module

Control Functions: Start, stop, navigation, and parameter editing

Power Specifications

Input Voltage: Supplied by connected PowerFlex drive

Power Source: Drive interface connection

Power Consumption: Low power operation

Power Supply Method: Direct connection through drive communication port

Protection Functions: Internal electronic protection

Communication & Interface

Communication Interface: Serial communication interface

Connection Method: Direct connection to compatible PowerFlex drives

Communication Function: Drive parameter access, configuration, and monitoring

Display Information: Operating status, parameters, alarms, and fault messages

Control Features: Navigation keys, parameter selection, and drive setup functions

Diagnostics: Real-time drive status and fault information display

Environmental

Operating Temperature: 0 to 50 °C

Storage Temperature: -40 to 85 °C

Humidity: Up to 95% RH, non-condensing

Installation Environment: Industrial control panel environment

Protection Rating: IP20

Dimensions & Weight

Dimensions (H × W × D): 191.1 × 25.2 × 93 mm

Weight: 0.11 kg
