Allen Bradley 1769-IF8 CompactLogix 8-Channel Analog Input Module

Overview

The Allen Bradley 1769-IF8 is a CompactLogix analog input module designed for acquiring multiple analog signals from industrial field devices. With 8 input channels, it is widely used in process control, machine monitoring, and automation systems requiring accurate measurement of current and voltage signals. The module delivers stable, high-resolution analog data conversion for CompactLogix PLC platforms.

General Information

Part Number: 1769-IF8

Manufacturer: Allen-Bradley (Rockwell Automation)

Brand: Allen-Bradley

Country of Origin: USA

Series: CompactLogix 1769

Type: Analog Input Module

Function: Converts analog field signals into digital values for PLC processing

Mounting: Installed on CompactLogix 1769 I/O chassis or DIN rail system

Technology: Multi-channel analog signal conditioning with A/D conversion

Power Specifications

Operating Voltage: 24 V DC (system backplane supply)

Power Consumption: Low power industrial analog module

Input Signal Types: Supports industrial current (e.g., 4–20 mA) and voltage (e.g., ±10 V DC)

Protection: Overvoltage protection and channel isolation

Indicators: LED status indicators for module health and channel activity

Communication & Interface

Bus System: CompactLogix 1769 backplane communication

Input Channels: 8 analog input channels

Signal Type: Current and voltage analog signals

Data Transfer: Real-time analog-to-digital conversion and transmission to PLC processor

Diagnostics: Built-in channel diagnostics and module fault detection

Environmental

Operating Temperature: 0 to 60 °C

Storage Temperature: −40 to 85 °C

Humidity: 5% to 95% non-condensing

Vibration Resistance: Industrial control cabinet rated

Protection Rating: IP20 for enclosed panel installation use

Dimensions & Weight

Dimensions (H × W × D): 118 × 52.5 × 87 mm

Weight: 0.45 kg

Reliable Multi-Channel Analog Performance — Ready for Industrial Deployment!
