Allen Bradley 1336-BDB-SP76D Gate Driver

Release time	May 7, 2026
Brand	Allen Bradley PLC
Product Numbe	1336-BDB-SP76D
Country Of Origin	USA
Dimensions	150 × 100 × 50 mm
Weight	0.5 kg
Condition	New & In Stock
Payment Methods	T/T, PayPal, Western Union
Lead Time	1-3 Working Days
Warranty	One Year
Courier partners	DHL, UPS, TNT, FedEx and EMS.

Request For Quotation [email protected]

Product Details
Frequently FAQ
Contact Us
Argument
Score

Overview

The Allen Bradley 1336-BDB-SP76D is a high-performance gate driver designed for motor control and industrial automation applications. It ensures precise switching of power devices such as IGBTs and MOSFETs, improving efficiency and reliability in variable frequency drives (VFDs) and other power electronic systems.

General Information

Part Number: 1336-BDB-SP76D

Manufacturer: Allen Bradley

Brand / Country of Origin: Rockwell Automation / USA

Type: Gate Driver / Motor Control Interface

Series: 1336

Mounting: Panel or DIN-rail compatible

Technology: Solid-state electronics for precise gate control, overcurrent and thermal protection

Power Specifications

Supply Voltage: 24 V DC nominal

Output Current: Specified per gate device requirements

Power Consumption: ≤ 15 W

Protection: Short-circuit, overvoltage, and thermal shutdown features

Indicators: Status LEDs for power and fault

Communication & Interface

Interface Type: Digital control signals (PWM, logic inputs)

Connection: Screw terminals for gate drive and control inputs

Application Role: Drives IGBT/MOSFET gates for precise switching in VFDs and industrial drives

Diagnostics: Fault monitoring, status feedback via LEDs

Environmental

Operating Temperature: −20 to +70 °C

Storage Temperature: −40 to +85 °C

Humidity: Up to 95% RH, non-condensing

Protection Rating: IP20 (suitable for industrial enclosure)

Dimensions & Weight

Dimensions (L × W × H): 150 × 100 × 50 mm

Weight: 0.5 kg
